The basic structure of the dust collection system is composed of three parts: fan, filter and dust collector, each part is installed in a vertical frame, steel plate shell, baking paint anti-rust, easy to operate and use. Fan adopts centrifugal fan, large air volume, high wind pressure, and adopts noise reduction measures, low noise. The filter adopts flat cloth bag group, each cloth bag is equipped with spring steel wire mesh, the filtering effect is good. The flyaway mechanism uses the motor to drive the eccentric wheel and the connecting rod to make the cloth bag shake and stick to the dust on the surface of the filter bag. The dust collector is equipped with an access door for easy maintenance and bag changing.
The following are the advantages of central dust collection system maintenance instructions:
A, advantages of central dust collection system Every 1000 hours to the air pump bearing LC-250 high drop point synthetic grease, replace the grease once a year.
Second, during the use of the equipment, the air pump filter is cleaned once every half month to the gas path.
Check the film in the pulse valve 1-2 times a year, and find that the damaged and aging should be replaced in time.
Four, advantages of central dust collection system often check the grease of the fuel tank of the fan reducer motor and add it in time.
Open the inspection door every week, check whether the dust bag is normal, whether the surface dust is too much, and find the cause and eliminate the fault.
6. If the fault is found, it should be stopped in time, find the cause, and then used after repair.
Dust collector, voltage, from the dust collector external wire street power supply can start to use, the initial operation, should pay attention to the fan rotation direction (such as reverse, need to replace the power wiring. The cover of the dust collector control cabinet can not be opened at will in the studio, if it is necessary to adjust the cleaning time, or repair the circuit, it should be stopped or cut off the power supply. According to the nature of dust and the size of dust concentration, adjust the timing of cleaning. Vacuum cover is a key part of the dust collector in the state, the use of units should be connected according to the size of the workpiece and the nature of the dust, close, seal, and design the principle of dust cover, the production of ideal dust cover.
advantages of central dust collection system When working, we can not open its lid casually, this is not allowed. When we need to adjust the cleaning time of the machine or check the circuit, the power supply needs to be cut off. In order to be able to work normally, dust cleaning work should be done. The cleaning time can be determined according to the capacity of dust, generally a class to clean three or four times. When we are in the dust, we need to stop the machine and open the sealed door for cleaning.
advantages of central dust collection system Cleaning mechanism, is the use of electric motor to drive the bias wheel, the connecting rod to make the cloth bag vibrate and clean the dust on the surface of the filter bag. Its control installation is divided into two kinds: automatic control and manual control. Automatic control means that when the fan continues the task, the advantages of central dust collection system active vibration cleaning mechanism on time, manual fan dust collector after the suspension of the active task of the cleaning mechanism, the active suspension after tens of seconds, can also start the dust cleaning motor at any time according to demand. Cleaning time length by the user to adjust the time relay. Structural performance features: advantages of central dust collection system, dust collector is a small volume, dust removal of air purification equipment. Suitable for a variety of vertical dust production points, flexible and convenient, local dust collection, local treatment, can be clean air. The basic structure is composed of dust removal box, centrifugal fan, filter bag (filter cartridge), dust collector and microcomputer controller, etc. The dust is sucked inside the dust collector box by the negative pressure of the fan through the dust suction pipe, and the coarse particle dust is initially filtered by the filter and directly dropped to the dust collector by the filter, and the fine dust is captured by the filter on the outer surface. Clean gas is filtered, decomposed and purified by the filter element into the clean room, and then discharged from the outlet by the fan.
The dust-containing gas enters the dust collector from the lower part of the dust collector and is filtered through the dust bag, and the clean air is discharged by the induced draft fan. After the dust collector works for a period of time, the dust on the filter bag gradually increases, causing the Yin force of the filter bag to rise, and the dust collector needs to be cleaned, and the dust collector will work normally after the cleaning is completed. advantages of central dust collection system The unit has six specifications, divided into three kinds, a kind of door, a kind of drawer, a kind of neither a door nor a drawer; The lower part of the addition is directly connected to the dust removal equipment such as the top of the warehouse, the silo, and the transportation of the belt transfer according to the requirements. The advantages of central dust collection system are installed in the vicinity of the mechanical equipment that produces dust. And by the user according to the size of the upper inlet of the dust collector, the metal or plastic pipe and dust collection cover (can also be designed by the manufacturer), the dust collector should check the access door before the work, the flange connection is sealed, so as to avoid air leakage, reduce the dust collection effect.
